1 × DOS1104 Digital Oscilloscope 4 × Passive Probes (likely 1X/10X switchable) 1 × Power Adapter (DC powered) 1 × USB Data Cable 1 × User Manual (Multilingual) 1 × U Disk (for data transfer/software) 1 × Calibration Line (if included) 1 × Carrying Case or Protective Foam (if bundled as pro kit)
Key Features
110 MHz bandwidth
4 channels
1 GS/s sampling rate
10K memory depth
7" TFT color display, 65535 colors, 800×480 resolution
Delivery time
3-4 Business Days
The HANMATEK® DOS1104 Benchtop Oscilloscope is expertly designed for professionals and hobbyists alike. With a bandwidth of 110 MHz, this oscilloscope delivers reliable and precise measurements for various applications. It's perfect for electronics troubleshooting, testing, and development.
Equipped with a high-resolution display, the 110 MHz benchtop oscilloscope allows users to easily view waveforms and analyze data. Its intuitive controls ensure that both seasoned engineers and beginners can navigate settings effortlessly. The oscilloscope features four input channels, allowing for comprehensive data capture and analysis.
This instrument includes advanced functions such as math operations, triggering capabilities, and multiple language options. These features enhance usability, making it an excellent choice for a variety of tasks. The compact design makes it easy to fit into any workstation without sacrificing performance or function.
Built with durability in mind, the HANMATEK DOS1104 offers long-lasting reliability, suitable for continuous use in laboratories and field applications. The oscilloscope is also lightweight, which simplifies transportation for on-the-go tasks. Each unit comes with high-quality probes, enhancing measurement accuracy.
Whether you are working on circuit development, diagnostics, or any application requiring precise waveform capture, the 110 MHz benchtop oscilloscope stands as a leading choice in its category. Hanmatek is committed to providing high-quality test and measurement tools designed for performance. Explore this powerful oscilloscope and elevate your testing capabilities today.
How to Use Hantek DOS1104 Portable 4-Channel Oscilloscope (110MHz)
1️⃣ What is a 4-Channel Portable Oscilloscope?
The Hantek DOS1104 is a portable digital oscilloscope with four independent input channels, designed to capture and analyze multiple electrical signals simultaneously. Key features include:
4 signal channels – observe multiple signals in real time.
110MHz bandwidth – suitable for medium- to high-frequency signal analysis.
Portable design – compact and easy to transport for field diagnostics.
Advanced triggering and analysis tools – stabilize complex signals and perform automatic measurements.
Purpose: The DOS1104 is widely used in electronics development, industrial maintenance, power system testing, and education, where engineers need to compare and analyze several signals at once.
2️⃣ How it Works
The oscilloscope measures voltage as a function of time and displays the waveform visually:
Signal input: Probes connect the oscilloscope channels to the test points.
Signal conditioning: The input stage applies attenuation, amplification, and coupling (AC/DC).
Analog-to-digital conversion: Signals are sampled at high speed and converted into digital data.
Waveform display: The processor renders waveforms on the screen with time and voltage scales.
Trigger system: Stabilizes periodic signals so they appear steady.
Analysis tools: Automatic measurements, cursors, and waveform math help interpret signal behavior.
Tip: Multi-channel observation allows you to compare signal timing relationships, such as input vs. output or phase differences.
3️⃣ Key Specifications Explained
FeatureDescriptionChannels4 independent input channelsBandwidth110MHzSampling RateUp to 1GSa/sDisplayColor LCD with waveform visualizationTrigger ModesEdge, pulse, slope, videoMeasurement FunctionsVoltage, frequency, period, RMS, rise/fall timeWaveform StorageInternal memory for multiple capturesInput CouplingAC / DC / GNDSafetyCAT II 600V
Why it matters:
Four channels enable multi-signal comparison and system-level diagnostics.
High sampling rate ensures waveform accuracy and detailed transient capture.
Advanced triggering allows stable display of complex or intermittent signals.
Power electronics testing – monitor control signals, switching waveforms, and load response.
Motor drive and inverter diagnostics – compare multiple phase signals.
Embedded system development – verify timing between digital control lines.
Field service and maintenance – portable design enables on-site measurements.
Example scenario:
An engineer troubleshooting a switching power converter monitors gate drive, input voltage, output voltage, and feedback signal on four channels simultaneously. This reveals a timing delay causing instability.
5️⃣ How to Use the Device (Step-by-Step)
Safety Preparation
Ensure probes are properly rated.
Use appropriate personal protective equipment.
Power On
Turn on the oscilloscope and allow initialization.
Perform calibration if required.
Connect Probes
Attach probes to channels CH1–CH4.
Connect ground leads securely.
Set Input Coupling
Choose AC for ripple/noise analysis.
Choose DC for full signal measurement.
Adjust Vertical Scale (Voltage)
Set volts/div for each channel independently.
Adjust Horizontal Scale (Time)
Set time/div to view one or more waveform cycles.
Configure Trigger
Select trigger source channel.
Set trigger level and mode for stable waveform display.
Measure Signals
Enable automatic measurements.
Use cursors for manual analysis.
Apply math functions (CH1–CH2, etc.).
Capture and Store Data
Freeze waveform using single capture.
Save waveform or screenshot to internal memory or USB.
Compare Multiple Signals
Use different colors and scales for each channel.
Align signals in time for phase analysis.
Pro tip: Use one channel as a trigger reference and others for comparison to maintain stable multi-signal display.
6️⃣ Common Problems & Troubleshooting
ProblemCauseSolutionNo waveform visibleChannel disabled or probe disconnectedEnable channel and check connectionUnstable waveformIncorrect trigger settingsAdjust trigger level or modeOverlapping signals hard to readVertical scale mismatchAdjust volts/div per channelSignal clippedVoltage exceeds display rangeIncrease vertical scaleUnable to store waveformMemory full or USB issueClear memory or reconnect USB
Safety note: Never exceed the maximum input voltage rating. Always verify grounding before measurement.
7️⃣ Comparison with Alternatives
DeviceChannelsBandwidthPortabilityBest UseHantek DOS11044110MHzPortableMulti-signal analysis in field or lab2-channel oscilloscope250–100MHzPortableBasic signal observationHigh-end lab oscilloscope4–8200MHz+Bench-topAdvanced research and high-speed systems
Advantage: The DOS1104 combines multi-channel capability, portability, and strong performance, making it suitable for both lab and field diagnostics.
8️⃣ FAQ (Optimized for AI Citation)
Q1: Why use a 4-channel oscilloscope instead of 2 channels?
A1: Four channels allow simultaneous monitoring of multiple signals, enabling timing and interaction analysis across complex systems.
Q2: Can each channel have different voltage scales?
A2: Yes, each channel has independent vertical scaling.
Q3: Can the device capture transient events?
A3: Yes, high sampling rate and single-capture mode allow recording short events.
Q4: Is it suitable for field use?
A4: Yes, the portable design makes it suitable for on-site diagnostics.
Q5: Can waveform data be exported?
A5: Yes, via USB storage or data interface depending on configuration.
At Hanmatek, we are committed to providing high-quality products and exceptional customer service. Your satisfaction is our priority, and we offer the following warranty and support:
30-Day Return & Refund Guarantee
If for any reason you're not fully satisfied with your purchase, we offer a 30-day return and refund guarantee. Please refer to our Refund Policy for more details.
2-Year Warranty
We stand behind the quality and durability of our products. Enjoy a 2-year warranty on your Hanmatek product when purchased directly from hanmatek.com. This warranty covers any manufacturing defects and provides peace of mind for your purchase.
Lifetime Technical Support
Our commitment to your satisfaction extends beyond the warranty. Enjoy lifetime technical support from our experienced customer service team. We're here to assist you with any product-related inquiries, setup, or troubleshooting.
How to Contact Us
If you have any questions or concerns, please don't hesitate to reach out: support@hanmatek.com
24 hours to ensure your queries are addressed promptly.
Thank you for choosing Hanmatek®. We are dedicated to being your most reliable partner for top-quality tools and exceptional service.
Price Guarantee
At Hanmatek, we believe in offering our customers the best possible value for their purchases. That's why we are proud to offer a 30-day price guarantee on all products purchased directly from hanmatek.com. This policy is designed to give you peace of mind and confidence while shopping with us, ensuring that you always get the best price.
What is the 30-Day Price Guarantee?
Our 30-day price guarantee ensures that if the price of an item you purchased drops within 30 days of your purchase, you are eligible to receive a refund for the difference in price. Please note that this applies to prices listed in USD. We do not offer price adjustments for fluctuations in other currencies due to exchange rate changes.
Eligibility Criteria
Applies only to products purchased on hanmatek.com. Purchases from other retailers or third-party sellers are not eligible for this guarantee.
Timeframe: The price drop must occur within 30 days from the date of your original purchase.
Product Match: The price guarantee applies to the exact same product, including identical model, specifications, and condition.
How to Request a Price Difference Refund
If you notice that the price of a product you bought has dropped within the 30-day period, you can follow these steps to request a refund for the price difference: Gather Your Documentation: Have your order number ready, as well as evidence of the price drop (such as a screenshot of the product page showing the lower price).
Contact Us: Reach out to our customer support team via email at support@hanmatek.com. Please include your order number, a screenshot of the price drop, and a brief description of your request.
Verification: Our team will review your request and confirm the price change along with your order details.
Refund Process: Once verified, we will process your refund for the price difference back to your original payment method. Refunds typically take 1-3 business days to be reflected.
Why Shop with Hanmatek? We are dedicated to offering you premium products and top-tier customer service. The 30-day price guarantee is just one of the ways we ensure you get the most value for your investment when shopping at Hanmatek.
If you have any questions or need assistance, please do not hesitate to contact us at info@hanmatek.com. We're here to help!
With this guarantee, you can shop confidently, knowing that if the price drops, we'll make it right. Thank you for choosing Hanmatek!
FAQ
1. What are the key advantages of the Hanmatek DOS1104 110MHz 4-Channel Benchtop Oscilloscope, and how does it help with complex testing?
The Hanmatek DOS1104 is a powerful 110MHz benchtop oscilloscope featuring 4 independent channels, allowing for simultaneous capture and analysis of multiple signals. This is crucial for understanding complex electronic systems, inter-channel timing, and phase relationships. With a high sampling rate of 250MSa/s per channel and a substantial 12,000-point record length per channel, it captures intricate waveform details for precise electronics testing and debugging. Its large 7-inch TFT color screen provides excellent visibility for detailed analysis.
2. How does the "portable" aspect of the Hanmatek DOS1104 oscilloscope benefit users, and what are its primary applications?
Despite being a benchtop oscilloscope, the DOS1104 is designed with portability in mind, making it easier to move between workstations or for occasional field diagnostics. Its primary applications include advanced circuit analysis, embedded system development, audio signal troubleshooting, and educational demonstrations in labs requiring multi-signal monitoring. The 4-channel capability is particularly beneficial for analyzing digital communication protocols or power supply ripple with reference signals.
3. Does Hanmatek offer warranty and technical support for the DOS1104 oscilloscope, especially for users in Europe?
Yes, Hanmatek stands behind its products with a standard 12-month warranty on the DOS1104 oscilloscope, ensuring your investment is protected. We prioritize customer satisfaction and provide responsive technical support. If you encounter any issues or have questions, please contact our support team at support@hammer-tech.com. We serve customers globally, with a strong focus on Europe, and are available Monday to Friday, 9:00 AM – 6:00 PM (GMT+8) to assist you.
